Automotive Oscillators Crystals

Differential LVDS OSC

SMD Type XTAL CMOS OSC Differential LVPECL OSC Differential LVDS OSC Differential HCSL OSC TCXO VCTCXO

Differential LVDS OSC

±25 ppm
±100 ppm
Tolerance Options(ppm)
-40~ +85°C
-40~+105°C
-40~+125°C
Operating Temp Range Options
Certification
Certification
Certification
Test Standards
Outline Model Dimension(mm) Frequency Range(MHz) Voltage(v) Stability Options(ppm) Operating Temp Range Options ECAD Specifications
CRYSTAL OSCILLATORS SMDF-751 7.0*5.0*1.4 13.500~160.000 +1.8、+2.5、+3.3
2.375~3.63		 ± 25 ~ ± 100 -20 ~ +70°C
-40 ~ +85°C
-40 ~ +105°C
-40 ~ +125°C
CRYSTAL OSCILLATORS SMDF-531 5.0*3.2*1.3 13.500~160.000 +1.8、+2.5、+3.3
2.375~3.63		 ± 25 ~ ± 100 -20 ~ +70°C
-40 ~ +85°C
-40 ~ +105°C
-40 ~ +125°C
CRYSTAL OSCILLATORS SMDF-321 3.2*2.5*1.1 13.500~200.000 +1.8、+2.5、+3.3
2.375~3.63		 ± 25 ~ ± 100 -20 ~ +70°C
-40 ~ +85°C
-40 ~ +105°C
-40 ~ +125°C
CRYSTAL OSCILLATORS SMDF-221 2.5*2.0*1.1 13.500~200.000 +1.8、+2.5、+3.3
2.375~3.63		 ± 25 ~ ± 100 -20 ~ +70°C
-40 ~ +85°C
-40 ~ +105°C
-40 ~ +125°C
